Tube Fitting Material
316 Stainless Steel
Specific Fitting Shape
Straight Adapter
Fitting Connection Type
Press x Male Pipe Thread
Tube Size
1-1/2 in x 1-1/2 in
Pipe Size - Pipe Fitting
1-1/2 in x 1-1/2 in
Standards
ASTM A312, ASTM A403, CRN 13492.5 A/B, IAPMO, IAPMO PS 117, ICC, ICC LC1002, NSF/ANSI 372, NSF/ANSI 61, TSSA/ASME B31.1, TSSA/ASME B31.3, TSSA/ASME B31.9
Pipe Size (Fittings)
1-1/2
Compliance
CRN 13492.5 A/B, IAPMO PS117, ICC-LC1002, NSF 372, NSF/ANSI 61
Temp. Range
0 Degrees to 250 Degrees F
Specific Pipe Fitting Shape
Adapter
Pipe Fitting Connection Type
Press x Male Pipe Thread
Fitting Side B Connection Type
MNPT
Fitting Side A Connection Type
Press-Fit
Fitting Body Material
316 Stainless Steel
Connection Type
Press-Fit x MNPT
End Connection Type
Press, Threaded
Maximum Operating Temperature
250 Degrees F
Stop and Shape
Straight Adapter
Fitting Side B Pipe Size
1 1/2 in
Pipe Size
1 1/2 in x 1 1/2 in
Fitting Pipe Size
1 1/2 in
Minimum Operating Temperature
0 Degrees F
Fitting Material
Stainless Steel
Maximum Operating Pressure
200 psi
Fitting Side A Pipe Size
1 1/2 in
Country of Origin (subject to change)
Germany
