| Property | Value |
|---|---|
| Item - Carbon Steel Grating | Bar Grating |
| Item | A1011 Carbon Steel Rectangular Grating |
| Surface - Carbon Steel Grating | Serrated |
| Span (Length) - Grating | 120 in |
| Width - Carbon Steel | 24 in |
| Height - Carbon Steel Grating | 1.25 in |
| Finish - Grating | Black Painted Steel |
| Bearing Bar Thickness | 3/16 in |
| Bearing Bar Spacing | 1 3/16 in |
| Cross Bar Spacing | 4 in |
| Material | Carbon Steel |
| Span | 120 |
| Surface | Serrated |
| Height | 1.25 in |
| Width | 24 |
| Uniform Load Rating @ Unsupported Length | 1480 lb/sq ft @ 2 ft |
| Surface Texture | Serrated |
| Nominal Size (WxL) | 24 in x 10 ft |
| System of Measurement | Inch |
| Application | Driveway Drains, Floor Drains, Storm Water Drains, Trench Drains |
| Top Surface | Serrated |
| Overall Height | 1 1/4 in |
| Material Grade | A1011 |
| For Use Indoors/Outdoors | Yes |
| Rating @ Unsupported Length | 1,480 lb/sq ft @ 2 ft |
| Standards | ISO 9001:2015 |
| Grating Finish | Black Painted |
| Shape | Rectangular Grating |
| Overall Length | 10 ft |
| Overall Width | 24 in |
| Weight | 181 lb |
| Finish | Black Painted Steel |
| Country of Origin (subject to change) | Taiwan, Province of China |
| Package Quantity | 1 |
Bar Grating, Serrated, 120 in L, 24 in W, 1.25 in H, Black Painted Steel Finish, EnjoyTool Select, Mfr#: 20188R125-B10
$576.99
Free shipping will be applied on orders over $50
A1011 Carbon Steel Rectangular Grating, Material Carbon Steel, Material Grade A1011, Overall Height 1 1/4 in, Overall Width 24 in, Overall Length 10 ft, Cross Bar Spacing 4 in, Bearing Bar Spacing 1 3/16 in, Bearing Bar Thickness 3/16 in, Top Surface Serrated, Weight 181 lb, Application Driveway Drains, Floor Drains, Storm Water Drains, Trench Drains, Finish Black Painted Steel, For Use Indoors/Outdoors Yes, Rating @ Unsupported Length 1,480 lb/sq ft @ 2 ft, Shape Rectangular Grating
9999 in stock
