| Property | Value |
|---|---|
| Shaft Length | 2 in |
| Application | Blowers, Fans and Air Circulators |
| RPM Range | 1,701-1,800 |
| Motor Mounting Position | Horizontal |
| No. of Speeds | 1 |
| Shaft Dia. | 5/8 in |
| HP | 1/2 |
| Motor Sub Application | Direct Drive Fan/Blower |
| Standards | CSA Certified, UL Recognized |
| Motor Service Factor | 1 |
| Voltage | 115/208-230V AC |
| Motor Bearings | Ball |
| Nameplate RPM | 1,725 |
| Motor Shaft Design | Keyed |
| Motor Thermal Protection | None |
| Motor Shaft Rotation | CW/CCW |
| Item | Direct Drive Blower Motor |
| Motor Application | HVAC/R |
| Voltage Compatibility | 115/200-230V AC, 115/208-230V AC, 115V AC, 208-230V AC |
| Motor Mounting Type | Cradle Base |
| Body Dia. | 6 1/2 in |
| Motor Enclosure Design | Totally Enclosed Air-Over |
| Duty | Continuous |
| Full Load Amps | 6.8/3.1/3.4 A |
| Max. Ambient Temp. | 40 Degrees C |
| Ins. Class | B |
| Overall Length | 10 13/16 in |
| Length Less Shaft | 8 13/16 in |
| Phase | Single |
| Motor Design | Split-Phase |
| Ring to Ring Center | 8 5/16 in |
| Resilient Ring Dia. | 2 1/2 in |
| Capacitor Required | No |
| Manufacturers Warranty Length | 1 yr |
| Frame | 56 |
| Hz | 60 Hz |
| Weight | 23 lb |
| Usable @ 200V | No |
| Number of Shafts | 1 |
| Motor Frame Material | Steel |
| Includes | Resilient Base |
| Stud Quantity | 4 |
| Duty Cycle | Continuous |
| Usable @ 208V | Yes |
| Mounting Holes | 4 |
| Number of Speeds | 1 |
| Mounting | Cradle Base |
| Country of Origin (subject to change) | Mexico |
| Package Quantity | 1 |
Mtr, Sp Ph, 1/2hp, 1725,115/208-230, 56, TEAO, Century, Mfr#: ARB2054L4
$305.99
Free shipping will be applied on orders over $50
Direct Drive Blower Motor, Single Phase, Motor Design Split-Phase, 1/2 HP, Nameplate RPM 1,725, No. of Speeds 1, Voltage 115/208-230V AC, Full Load Amps 6.8/3.1/3.4 A, 56 Frame, Usable @ 208V Yes, Usable @ 200V No, Motor Thermal Protection None, 60 Hz Hz, Motor Service Factor 1, Ins. Class B, Motor Shaft Rotation CW/CCW, Max. Ambient Temp. 40 Degrees C, Duty Cycle Continuous, Motor Enclosure Design Totally Enclosed Air-Over, Motor Mounting Type Cradle Base, Motor Mounting Position Horizontal
9999 in stock
