| Property | Value |
|---|---|
| Motor Mounting Type | Cradle Base |
| Stud Size | #10-32 |
| Item | Direct Drive Blower Motor |
| Motor Design | Split-Phase |
| Application | Blowers, Fans and Air Circulators |
| Motor Shaft Design | Keyed |
| Includes | 5/8 in Diameter Bushing, Resilient Base |
| Mounting Stud Length | 1/2 in |
| Nameplate RPM | 1,725 |
| Phase | Single |
| Motor Enclosure Design | Totally Enclosed Air-Over |
| Bolt Circle Dia. | 5 13/16 in |
| RPM Range | 1,701-1,800 |
| Voltage Compatibility | 115/200-230V AC, 115/208-230V AC, 115V AC, 208-230V AC |
| Mounting Stud Pattern | 4-1/8 in x 4-1/8 in |
| Duty | Continuous |
| Motor Application | HVAC/R |
| Voltage | 115/208-230V AC |
| Frame | 56Z |
| Capacitor Required | No |
| Motor Service Factor | 1.35 |
| Full Load Amps | 5.6/2.8 A |
| Standards | CSA Certified, UL Recognized |
| Max. Ambient Temp. | 40 Degrees C |
| HP | 1/3 |
| Motor Mounting Position | All Angle |
| Motor Bearings | Ball |
| Shaft Length | 1 5/8 in |
| Motor Sub Application | Direct Drive Fan/Blower |
| Manufacturers Warranty Length | 1 yr |
| No. of Speeds | 1 |
| Motor Shaft Rotation | CW/CCW |
| Motor Thermal Protection | None |
| Mounting Stud Location | Shaft End |
| Body Dia. | 6 1/2 in |
| Shaft Dia. | 1/2 in |
| Overall Length | 10 in |
| Length Less Shaft | 8 3/8 in |
| Ins. Class | B |
| Hz | 60 Hz |
| Stud Quantity | 4 |
| Mounting Holes | 4 |
| Motor Frame Material | Steel |
| Number of Shafts | 1 |
| Weight | 24 lb |
| Usable @ 200V | No |
| Duty Cycle | Continuous |
| Usable @ 208V | Yes |
| Number of Speeds | 1 |
| Mounting | Cradle Base |
| Country of Origin (subject to change) | Mexico |
| Package Quantity | 1 |
Motor, Sp Ph, 1/3 HP, 1725,115/208-230V, 56Z, Century, Mfr#: ARB2034L4
$244
Free shipping will be applied on orders over $50
Direct Drive Blower Motor, Single Phase, Motor Design Split-Phase, 1/3 HP, Nameplate RPM 1,725, No. of Speeds 1, Voltage 115/208-230V AC, Full Load Amps 5.6/2.8 A, 56Z Frame, Usable @ 208V Yes, Usable @ 200V No, Motor Thermal Protection None, 60 Hz Hz, Motor Service Factor 1.35, Ins. Class B, Motor Shaft Rotation CW/CCW, Max. Ambient Temp. 40 Degrees C, Duty Cycle Continuous, Motor Enclosure Design Totally Enclosed Air-Over, Motor Mounting Type Cradle Base, Motor Mounting Position All Angle
