| Property | Value |
|---|---|
| Resilient Ring Dia. | 2 1/4 in |
| Motor Design | Capacitor-Start |
| Length Less Shaft | 9 13/16 in |
| Ins. Class | B |
| Ring to Ring Center | 9 1/2 in |
| Voltage | 115/208-230V AC |
| Motor Sub Application | Direct Drive |
| Motor Application | HVAC/R |
| Standards | CSA Certified, UL Recognized |
| Motor Service Factor | 1.25 |
| Item | Direct Drive Blower Motor |
| Motor Thermal Protection | Auto |
| No. of Speeds | 1 |
| Body Dia. | 5 5/8 in |
| Motor Shaft Rotation | CW/CCW |
| Hz | 60 Hz |
| Max. Ambient Temp. | 40 Degrees C |
| Frame | 56 |
| Motor Enclosure Design | Open Dripproof |
| Capacitor Required | Included |
| Motor Mounting Type | Cradle Base |
| RPM Range | 1,701-1,800 |
| HP | 3/4 |
| Shaft Dia. | 5/8 in |
| Voltage Compatibility | 115/200-230V AC, 115/208-230V AC, 115V AC, 208-230V AC |
| Shaft Length | 1 7/8 in |
| Phase | Single |
| Motor Mounting Position | All Angle |
| Duty | Continuous |
| Motor Shaft Design | Keyed |
| Nameplate RPM | 1,725 |
| Motor Bearings | Ball |
| Mounting Stud Pattern | 3-5/8 in x 3-5/8 in |
| Full Load Amps | 10.6 A |
| Stud Quantity | 4 |
| Number of Shafts | 1 |
| Duty Cycle | Continuous |
| Usable @ 208V | Yes |
| Usable @ 200V | No |
| Includes | Capacitor |
| Conduit Box Position | F3 |
| Mounting | Cradle Base/Stud |
| Number of Speeds | 1 |
| Country of Origin (subject to change) | Mexico |
| Package Quantity | 1 |
Mtr, Cap St, 3/4hp, 1725,115/208-230, 56, ODP, EnjoyTool Select, Mfr#: 4YU35
$412.99
Free shipping will be applied on orders over $50
Direct Drive Blower Motor, Single Phase, Motor Design Capacitor-Start, 3/4 HP, Nameplate RPM 1,725, No. of Speeds 1, Voltage 115/208-230V AC, Full Load Amps 10.6 A, 56 Frame, Usable @ 208V Yes, Usable @ 200V No, Motor Thermal Protection Auto, 60 Hz Hz, Motor Service Factor 1.25, Ins. Class B, Motor Shaft Rotation CW/CCW, Max. Ambient Temp. 40 Degrees C, Duty Cycle Continuous, Motor Enclosure Design Open Dripproof, Motor Mounting Type Cradle Base, Motor Mounting Position All Angle
9999 in stock
