Welding Processes
Flux-Cored Welding (FCAW), MIG Welding (GMAW), Stick Welding (SMAW), TIG Welding (GTAW)
Maximum Wire Diameter
0.035 in (Flux-Cored), 0.035 in (Solid)
MIG Welding Maximum Output Current
140 A
For Material Type
Mild Steel, Stainless Steel
Max. Wire Diameter
0.035 in (Flux-Cored)
Welder Kit Type
MIG/Stick Package
Amperage Range
10 A to 140 A
MIG Welding Minimum Output Current
30 A
For Minimum Material Thickness
24 ga (Steel)
Max. Amperage Range (MIG)
Less than 150 A
Kit Includes
Contact Tips, Flow Gauge/Regulator u0026 Gas Hose, Flux-Cored Wire, MIG Gun, Solid Wire, Stick Electrode Holder with Cable, Work Cable with Clamp
For Wire Type
Flux-Cored, Solid
Application
Automotive, Brewery, Distillery, Maintenance and Repair, Repair Welding
Features
Compact Design, Easy To Use, Versatile Performance
Includes
(3) 0.025 in (0.6 mm) tapered contact tips, (3) 0.035 in (0.9 mm) tapered contact tips, 0.025 - .035 in (0.6 - 0.9 mm) wire diameter dual track drive roll for MIG and flux-cored welding (KP2948-1), Electrode holder with 10 ft. cable for stick welding, Gas nozzle for MIG welding, Gasless nozzle for Innershield(R) welding, Harris(R) 3000290 Gas Regulator (S25805) and 52 in (1.3 m) hose (S19303) for use with Ar/ CO2 blend gases., Magnum(R) PRO 100L gun and 10 ft. (3.0 m) cable assembly with brass connection and 8-pin trigger connector (K530-7)., Sample spool of .025 in (0.6 mm) diameter SuperArc(R) L-56(R) premium MIG wire, Sample spool of .035 in (0.9 mm) diameter Innershield(R) NR(R)-211-MP flux-cored wire, Work clamp and 10 ft. (3.0 m) cable
Remote Connection Type
8-Pin (Lincoln)
Maximum Wire Feed Speed
500 in/min
MIG Welding Output @ Duty Cycle
95 A @ 18.75V, 60%
Input Voltage (Nominal)
120V
For Maximum Material Thickness
1/4 in (Steel)
Process
Flux-Cored Welding (FCAW), MIG Welding (GMAW), Stick Welding (SMAW), TIG Welding (GTAW)
brand-mfr model
LINCOLN ELECTRIC - K4498-1
TIG Welding Minimum Output Current
10 A
TIG Welding Output @ Duty Cycle
115 A @ 14.6 V, 60%
Stick Welding Maximum Output Current
90 A
Rated Output at Duty Cycle (Stick)
80 A @ 60%
TIG Welding Maximum Output Current
120 A
Stick Welding Output @ Duty Cycle
80 A @ 23.2 V, 60%
Max. Amperage Range (TIG)
Less than 150 A
Max. Amperage Range (Stick)
Less than 150 A
Stick Welding Minimum Output Current
25 A
Country of Origin (subject to change)
Mexico
