Item
Short-Handled Selector Switch
Action
Maintained/Maintained/Momentary
Operator Head Material
Plastic
NEMA Rating
12, 13, 3, 3R, 4
Switch Operation @ Position A
XOOX
Switch Operation @ Position B
OXOX
Standards
CE, CSA LR24590 Class 3211 03, UL E42259 CCN NKCR
Switch Operation @ Position C
OXXO
Switch Operation @ Position D
No Fourth Position
Operator Position Information
3 positions
Product Or Component Type
head for selector switch
Device Presentation
basic element
Cap/Operator Or Lens Colour
black
Operator Profile
black standard knob, standard handle
Product Certifications
CE || UL listed file E42259 CCN NKCR || CSA LR24590 class 3211 03
Nema Degree Of Protection
NEMA 1/2/3/3R/4/6/12/13
Contacts Type And Composition
without contact block
Operator Illumination
Non-Illuminated
Hazardous Location Specification
Not Rated
Switch Function @ 4th Position
No Fourth Position
Switch Function @ 1st Position
Not Applicable
Switch Function @ 3rd Position
Not Applicable
Key Removal Position
Not Applicable
NEMA Enclosure Rating
1, 12, 13, 2, 3, 3R, 4
Operator Head Type
Short-Handled Knob
Switch Function @ 2nd Position
Not Applicable
Manufacturer Warranty Length
18 mo
Includes Operator Key
Not Applicable
Panel Cutout Diameter
30 mm
Country of Origin (subject to change)
Mexico
