| Property | Value |
|---|---|
| Item | Overload Relay |
| Item - Relay | IEC Style Overload Relay |
| Use With - Contactors and Starters | Mfr. Series 3RT202 Contactors |
| Current Range | 0.10 to 0.40A |
| Overload Relay Current Range | 0.10 to 0.40A |
| NEMA Size | Not Applicable |
| Trip Class - Overload | 10, 20, 30, 5 |
| Width | 1.77 |
| Number of Poles | 3 |
| Frame / Series / Class / Code | S0 |
| Sensing Method | Electronic |
| Reset Type - Relay | Auto, Manual |
| Height | 3.42 |
| Depth | 3.30 |
| Trip Class | 5E/10E/20E/30E |
| For Use With | 3RT202 Contactors |
| Body Height - Relay | 3.42 in |
| Features | Earth Fault Detection, Manual and Auto Reset |
| Body Depth - Relay | 3.3 in |
| Overall Height - Relay | 3.42 in |
| Body Width - Relay | 1.77 in |
| Standards | Lead CAS-No. 7439-92-1 Greater Than 0, 1 % (w/w), REACH Art 33 Duty to Inform According to the Current List of Candidates, RoHS 07/01/2006, WEEE (2012/19/EU) Take-Back Obligation |
| Separate Mounting | Yes, Additional Items Needed |
| Starter Type | IEC |
| Type of actuation | AC |
| Number of auxiliary contacts as opener | 1 |
| Power loss per pole, current-dependent [PlIp] | 0.03 watt |
| description of product type | 3RB3 |
| Connection type | Screw connection |
| Release class | adjustable |
| Number of auxiliary contacts as shutter | 1 |
| Lowest value adjustable current range | 0.1 ampere |
| Greatest value adjustable current range | 0.4 ampere |
| Number of auxiliary contacts as changer | 0 |
| External reset possible | Yes |
| Overall Height | 6.13 in |
| Compatible with Series | SIRIUS |
| Minimum Overload Relay Current Setting | 0.1 A |
| Minimum Operating Temperature | -13 Degrees F |
| Body Depth | 2.78 in |
| Body Height | 6.13 in |
| Maximum Voltage Rating | 690V AC |
| Maximum Overload Relay Current Setting | 0.4 A |
| Body Width | 1.77 in |
| Reset Type | Auto, Manual |
| Relay Style | IEC |
| Maximum Operating Temperature | 140 Degrees F |
| Includes Mounting Hardware | Not Applicable |
| Phase | Three |
| Overload Protection Type | Electronic |
| Frame Size | S0 |
| Mounting Style | Direct To Contactor |
| IP Rating | IP20 |
| Number of Required Thermals | Not Applicable |
| Includes Thermal Units | Not Applicable |
| Auxiliary Contact Form | 1NO/1NC |
| Terminal Connection Type | Screw Terminals |
| Country of Origin (subject to change) | Czechia |
| Package Quantity | 1 |
Overload Relay, 0.10 to 0.40A, 3P, NEMA S0, Siemens, Mfr#: 3RB31234RB0
$230.99
Free shipping will be applied on orders over $50
Overload Relay, Auxiliary Contact Form 1NO/1NC, Maximum Overload Relay Current Setting 0.4 A, Minimum Overload Relay Current Setting 0.1 A, Trip Class 5E/10E/20E/30E, Maximum Voltage Rating 690V AC, NEMA Size Not Applicable, Number of Poles 3, Number of Required Thermals Not Applicable, Reset Type Auto, Manual, Includes Thermal Units Not Applicable, Mounting Style Direct To Contactor, Terminal Connection Type Screw Terminals, Compatible with Series SIRIUS, Frame Size S0, Relay Style IEC
9999 in stock
