Specific Fitting Shape
Straight Connector
Standards
ANSI LC4/CSA 6.32, IAPMO/UPC LC-4, ICC-ES PMG 1502, IFGC International Fuel Gas Code, NFPA 30 Flammable and Combustible Liquids Code, NFPA 30A Code for Motor Fuel Dispensing Facilities and Repair Garages, NFPA 31 Standard for the Installation of Oil Burning Equipment (Supply Line Only), NFPA 54/Z223.1 National Fuel Gas Code, NFPA 58 Liquified Petroleum Gas Code, UPC Chapter 12 Fuel Piping
Fitting Side B Tube Outer Diameter
1/2 in
Stop and Shape
Dimple Center Stop Straight Connector
Connection Type
Press-Fit x Press-Fit
Includes Center Stop
Dimple Center Stop
Maximum Operating Temperature
180 Degrees F
Compatible Tube Material
Copper
Fitting Copper Tube Size
1/2 in
For Tube OD
1/2 in x 1/2 in
Minimum Operating Temperature
-40 Degrees F
Fitting Side A Connection Type
Press-Fit
Compatible Copper Tube Type
Type G, Type K, Type L
Copper Tube Size
1/2 in x 1/2 in
Fitting Side A Tube Outer Diameter
1/2 in
Fitting Side B Connection Type
Press-Fit
Maximum Operating Pressure
200 psi
Fitting Side A Copper Tube Size
1/2 in
Fitting Side B Copper Tube Size
1/2 in
Application
Natural Gas, Non-Potable Water, Propane
Country of Origin (subject to change)
United States
