Promotion Restriction | Not eligible for promotion |
Item | Hydraulic Pump |
Oil Capacity (Cu.-In.) | 127 cu in |
Reservoir Capacity (Gal.) | 0.54 gal |
Oil Displacement @ 0 PSI | 60.00 cu in/min |
Oil Displacement @ 10,000 PSI | 10 cu in/min |
Operating Air PSI | 40 to 125 |
Air Consumption (SCFM) | 12 |
Height (In.) | 8.3125 in |
Actuation Type | Foot, Hand |
Length (In.) | 12.4375 in |
Includes | Air and Hydraulic Inlet Filter, Air Exhaust Muffler |
dBA | 76 |
Features | Ergonomic Design, Pedal Lock Function, Pressure Relief Valve |
Air Inlet NPT (In.) | 1/4 |
Fluid Port NPT (In.) | 3/8 |
Built-In | Internal Pressure Relief Valve |
Treadle | Three Position |
Type | Air Powered |
Capacity (PSI) | 10,000 |
Width (In.) | 6.5 in |
Overall Width | 6.5 in |
Overall Height | 8 in |
Overall Length | 13.6 in |
Reservoir Capacity | 127 cu in |
Displacement @ No Load | 60 cu in/min |
Control Valve Function | Advance, Hold, Retract |
Sound Level - Maximum | 76 dBA |
Treadle Design | Three Position |
Air Intake Pressure - Maximum | 125 psi |
Air Consumption - Maximum | 12 scfm |
Control Valve Type | 3-Position, 3-Way |
Media Intake Connection Size | 3/8 in |
Air Intake Connection Size | 1/4 in |
Flow Rate - Maximum | 10 cu in/min |
Air Intake Connection Type | FNPT |
Operating Pressure - Maximum | 10,000 psi |
Country of Origin (subject to change) | United States |
Package Quantity | 1 |
Turbo II Air Hydraulic Pump, Hand/Foot Operated 3/3 Treadle Valve, 127 in3 Usable Oil, ENERPAC, Mfr# PATG1102N
$1164,00
-$67.9 / ea
with subscription
Free shipping will be applied on orders over $50
Hydraulic Pump, Reservoir Capacity 127 cu in, Air Intake Pressure - Maximum 125 psi, Air Intake Connection Size 1/4 in, Operating Pressure - Maximum 10,000 psi, Displacement @ 10,000 PSI 10 cu in/min, Sound Level - Maximum 76 dBA, Control Valve Type 3-Position, 3-Way, Actuation Type Foot, Hand, Air Consumption - Maximum 12 scfm, Air Intake Connection Type FNPT, Control Valve Function Advance, Hold, Retract, Displacement @ No Load 60 cu in/min
9999 in stock
Must order in multiples of 1
