| Item | Range 5-50 Flowmeter, Scfh Air With Ss V |
| Accuracy | 3% |
| Product Type | Variable Area Flowmeter |
| Shaft Material | Not Applicable |
| Flow Rate - Minimum | 5 scfh |
| Wetted Material | Aluminum, Buna-N, Glass, K500 Nickel-Copper Alloy, Neoprene, Polycarbonate, Stainless Steel, Tungsten Carbide |
| Overall Height | 8.8 in |
| Rotor Material | Not Applicable |
| Output Type | Not Applicable |
| Includes Totalizer | Not Applicable |
| Unit Of Measure | Gallons, Liters |
| For Pipe Size | 1/4 in |
| Voltage - Maximum | Not Applicable |
| Frequency - Maximum | Not Applicable |
| Includes Pressure Gauge | Not Applicable |
| Seal Material | Not Applicable |
| Overall Length | 3.6 in |
| Overall Width | 1.5 in |
| Media Temperature - Minimum | Not Applicable |
| Includes Flow Rate Adjustment Knob | Yes |
| Operating Pressure - Maximum | 100 psi |
| Frequency - Minimum | Not Applicable |
| Flow Rate - Maximum | 50 scfh |
| Pulse Rate | Not Applicable |
| Housing Material | Polycarbonate |
| Compatible Flow Material | Air |
| O-Ring Material | Buna-N, Neoprene |
| Display Type | Not Applicable |
| Mounting Orientation | Vertical |
| Connection Size | 1/4 in |
| Cable Length | Not Applicable |
| Connection Type | FNPT |
| Flowmeter Type | Variable Area |
| Viscosity - Maximum | Not Applicable |
| Standards | EU Directive 2011/65/EU, RoHS II Compliant |
| Media Temperature - Maximum | 130 Degrees F |
| Country of Origin (subject to change) | United States |
| Package Quantity | 1 |
Range 5-50 Flowmeter, Scfh Air With Ss V, DWYER INSTRUMENTS, Mfr# RMB-52-SSV
$75,39
-3% / ea
with subscription
Free shipping will be applied on orders over $50
Range 5-50 Flowmeter, Scfh Air With Ss V, Product Type Variable Area Flowmeter, Flowmeter Type Variable Area, Accuracy 3 Percent, Connection Size 1/4 in, Connection Type FNPT, Compatible Flow Material Air, Media Temperature - Maximum 130 Degrees F, Media Temperature - Minimum Not Applicable, Viscosity - Maximum Not Applicable, Voltage - Maximum Not Applicable, Housing Material Polycarbonate, Rotor Material Not Applicable, O-Ring Material Buna-N, Neoprene, Seal Material Not Applicable
9999 in stock
Must order in multiples of 1
Subtotal:
$75.39
