| Property | Value |
|---|---|
| Item | Rigid Shaft Coupling |
| Shaft Locking Type - Couplings | 1 Piece Clamp |
| System of Measurement | Inch |
| Bore Dia. | 3/4 in |
| Material - Couplings | 303 Stainless Steel |
| Outside Dia. | 1 1/2 in |
| Overall Length | 2 1/4 in |
| With Keyway / Without Keyway | Without Keyway |
| Finish | Bright |
| Max. Torque | 950 in-lb |
| Type | One Piece Clamp Type, Without Keyway |
| Design | Four Vibration Resistant Socket Capscrews |
| Item - Rigid Shaft Couplings | Rigid Shaft Coupling |
| Material | 303 Stainless Steel |
| Clearance Dia. (In.) | 1.842 |
| Standards | ANSI, Conflict Minerals Compliant, REACH Compliant, RoHS3 Compliant |
| Screw Size (In.) | 1/4-28 |
| Max. Torque (In.-Lbs.) | 950 |
| Screw Size | 1/4 |
| Application | For Applications where Alignment is Critical, Particularly when no Backlash is Desired and Flexibility is not Required, Useful when Timing, Joining and/or Aligning Shafts at Lower Speeds and Torque |
| Machined From | Bar Stock |
| Clearance Dia. | 1.842 in |
| Provides | Extra Holding Power for Higher Load Applications without Marring Shafts |
| Screw Material | Stainless Steel |
| Bore Tolerance | +0.0020 in / +0.0005 in |
| Recommended Gap | Not Applicable |
| Features | Precision Honed Bores, Vibration-Resistant Screws |
| Maximum Speed | 4,000 RPM |
| Coupling Material Finish | Bright |
| Bore Diameter 2 | 3/4 in |
| Coupling Material | Stainless Steel |
| Coupling Construction | One-Piece |
| Maximum Torque | 950 in-lb |
| Keyway Width 2 | Not Applicable |
| Included Screws | (4) Clamp Screws |
| Maximum Operating Temperature | 350 Degrees F |
| Shaft Tolerance | +0.0000 in / -0.0005 in |
| Minimum Operating Temperature | -40 Degrees F |
| Minimum Bore Diameter | 3/4 in |
| Screw Material Finish | Bright |
| Keyway Depth 2 | Not Applicable |
| Keyway Depth 1 | Not Applicable |
| Screw Material Grade | 18-8 300 Series |
| Shaft Locking Type | Clamp On |
| Bore Type | Round |
| Keyway Width 1 | Not Applicable |
| Coupling Material Grade | 303 |
| Screw Thread Size | 1/4 |
| Zero Backlash | Yes |
| Resistance Properties | Corrosion Resistant |
| Maximum Bore Diameter | 3/4 in |
| Clearance Diameter | 1.84 in |
| Bore Diameter 1 | 3/4 in |
| Fastener Tightening Torque | 110 lb-in |
| Coupling Outside Diameter | 1 1/2 in |
| Screw Location from Center | 0.545 in |
| Different Bore Sizes | No |
| Number of Locking Screws | 4 |
| Country of Origin (subject to change) | United States |
| Package Quantity | 1 |
Coupling, One Piece, Bore Dia 3/4 In, Ruland, Mfr#: CLX-12-12-SS
$105.99
Free shipping will be applied on orders over $50
Rigid Shaft Coupling, Bore Diameter 1 3/4 in, Bore Diameter 2 3/4 in, Bore Type Round, Clearance Diameter 1.84 in, Coupling Construction One-Piece, Coupling Material Stainless Steel, Coupling Outside Diameter 1 1/2 in, Different Bore Sizes No, Keyway Depth 1 Not Applicable, Keyway Depth 2 Not Applicable, Minimum Bore Diameter 3/4 in, Keyway Width 1 Not Applicable, Keyway Width 2 Not Applicable, Maximum Bore Diameter 3/4 in, Maximum Speed 4,000 RPM, Maximum Torque 950 in-lb
9999 in stock
