Item | Safety Switch |
Protection Method | Fusible |
Duty | General |
Voltage | 240V AC |
Phase | 1 |
HP | 3 hp @ 240V AC |
NEMA Enclosure Type | 1 |
IP Rating | 20 |
Number of Wires | 3 |
Number of Poles | 2 |
Contact Form | 2PST |
Amps AC | 30 A |
Metallic / Non-Metallic | Metallic |
Material of Construction | Steel |
Fusible / Nonfusible | Fusible |
Height | 9.2 in |
Width | 7.2 in |
Depth | 3.6 in |
Fuse Kit (Class R) | Mfr. No. DRK30 |
Standards | UL listed |
For Use With | Class H, K, R, T Fuse |
Fuse Type | Class H, K, or R |
Mounting | Surface |
Electrical Connection | Lugs |
Enclosure Depth | Less than 6 inches |
Features | Mercury Free, PVC Free |
Neutral Assembly Included | Yes |
Weight | 7.7 kg |
Gauge/Conductor | 12 to 6 AWG (Aluminum), 14 to 6 AWG (Copper) |
Enclosure Type | Enclosed |
Enclosure Material | Galvanized Steel |
Includes Neutral Assembly | Yes |
NEMA Enclosure Rating | 1 |
UL 98 Certification | Yes |
Environment | Indoor |
Horsepower @ 240V AC | 3 hp |
Enclosure Height | 0 to 9 3/4 inches |
Extra Features | Neutral Assembly |
Current Rating | 30 A |
UL Fuse Class | H, K, R |
For Fuse Class | Class H, Class K, Class R |
Enclosure Width | 0 to 9 3/4 inches |
Housing Material | Steel |
Current Type | AC |
Mounting Style | Surface Mount |
Compatible with Manufacturer Model Number | DRK30 |
Compatible Manufacturer Part Number | DRK30 |
Compatible with Manufacturer Part Number | DRK30 |
Compatible with Manufacturer Model Number [NEW] | DRK30 |
Country of Origin (subject to change) | Mexico |
Package Quantity | 1 |
Fusible Safety Switch, General Duty, 240V AC, 2PST, 30 A, NEMA 1, SQUARE D, Mfr# D221N
$66,49
Free shipping will be applied on orders over $50
Safety Switch, Compatible with Manufacturer Model Number DRK30, Contact Form DPST, Current Rating 30 A, Depth 3 3/4 in, Duty Standard, Enclosure Type Enclosed, Environment Indoor, For Fuse Class Class H, Class K, Class R, Fuse Kit (Class R) Mfr. No. DRK30, Height 9 1/4 in, Horsepower @ 240V AC 3 hp, Housing Material Steel, IP Rating IP20, Mounting Style Surface Mount, NEMA Enclosure Rating 1, Neutral Assembly Included Yes
9999 in stock
Must order in multiples of 1
Subtotal:
$66.49
