Type of Operator
3-Position Selector Switch
Standards
CEC, NEC, UL 1203, UL 508, UL 698
Contact Rating
10A @ 600V AC
Action
Maintained/Maintained/Momentary
Safety Rating
Class 1, Division 1 and 2, Groups C, D; Class 2, Division 1 and 2, Groups E, F, G; and Class 2I
Switch Function @ 1st Position
On
Operator Head Material
Aluminum
Lamp Voltage - Maximum
Not Applicable
Operator Head Type
Short-Handled Knob
Switch Function @ 4th Position
No Fourth Position
Lamp Module Type
Not Applicable
DC Contact Rating
Not Applicable
Key Removal Position
Not Applicable
Hazardous Location Specification
Class I, Div 1 and 2, Group C, D, Class II, Div 1 and 2, Group E, F, G, Class III, Div 1 and 2
AC Contact Rating
10 A @ 600 V
Panel Cutout Diameter
Not Applicable
Switch Function @ 3rd Position
Momentary
NEMA Enclosure Rating
3, 7, 9
Includes Operator Key
Not Applicable
Metal Operator Head Finish
Natural
Operator Illumination
Non-Illuminated
Switch Function @ 2nd Position
Off
Country of Origin (subject to change)
Mexico
