| Voltage | 120V AC |
| Shifting Technology | Direct |
| Pipe Size | 1/8 in |
| Valve Actuator / Return | Solenoid / Spring |
| Body Style | Stackable |
| Power Consumption | 4.8 W |
| Overall Width | 1 in |
| Ambient Temp. Range | 0 Degrees to 122 Degrees F |
| Coefficient of Volume | 0.048 |
| Operational Pressure Range | 0 to 150 psi |
| Pressure Range | 0 to 150 psi |
| Electrical Connections | DIN Connectors |
| NEMA Classification | NEMA 4 |
| Actuator/Return | Solenoid/Spring |
| Overall Height | 2 11/16 in |
| Overall Length | 1 5/8 in |
| Standards | CSA #LR51090, UL #MH13513 |
| Air Valve Type | 3-Way, 2-Position |
| Item | Solenoid Air Control Valve |
| Max. CFM - Valves | 1.8 cfm |
| Normally Open / Normally Closed | Normally Closed |
| CFM | 1.8 |
| Valve Ways and Positions | 3-Way/2-Position |
| Country of Origin (subject to change) | United States |
| Package Quantity | 1 |
Solenoid Air Control Valve, 1/8 In, 120VAC, ARO, Mfr# CAT33S-120-A
$87.93
Free shipping will be applied on orders over $50
Solenoid Air Control Valve, Valve Ways and Positions 3-Way/2-Position, Voltage 120V AC, Valve Actuator / Return Solenoid / Spring, Pipe Size 1/8 in, Max. CFM - Valves 1.8 cfm, Operational Pressure Range 0 to 150 psi, NEMA Classification NEMA 4, Normally Closed, Body Style Stackable, Coefficient of Volume 0.048, DIN Connectors Electrical Connections, Shifting Technology Direct, Power Consumption 4.8 W, Ambient Temp. Range 0 Degrees to 122 Degrees F, Overall Height 2 11/16 in
9999 in stock
Must order in multiples of 1
Subtotal:
$87.93
