| Item | Split-Bolt Connector |
| Connects | Copper to Copper Wire |
| Wire Range w/Equal Main and Tap (AWG) | 8 sol to 4 sol |
| Min. Tap Conductor w/1 Max. Main (AWG) | 14 sol |
| Material | Bronze Alloy |
| Pressure Bar Material | Copper |
| Standards | CSA Certified, UL 486B |
| Head Style | Hex Head |
| UL Standards | UL 486A-486B |
| Wire Size Range (Run) | (2) 8 AWG - (2) 4 AWG |
| Overall Length | 1.06 in |
| For Maximum Equal Wire Size | 4 AWG |
| Maximum Voltage | 600 V |
| Hex Nut Size | 0.719 in |
| Special Features | Corrosion Resistant, High Strength |
| Overall Width | 0.53 in |
| For Maximum Tap Wire Size | 4 AWG |
| Body Finish | Plain |
| RoHS Compliant | Yes |
| Minimum Tap Conductor w/1 Maximum Main (AWG) | 14 sol |
| Compatible Manufacturer Model Number | 4H |
| For Minimum Run Wire Size | (2) 8 AWG |
| For Minimum Tap Wire Size | 8 AWG |
| For Minimum Equal Wire Size | 8 AWG |
| Head Width | 0.53 in |
| For Run Wire Size | 4 AWG, 6 AWG |
| For Maximum Run Wire Size | (2) 4 AWG |
| Body Material | Bronze |
| Wire Range with Equal Main and Tap | 8 AWG - 4 AWG |
| Torque | 135 in-lb |
| For Conductor Material | Copper |
| Features | Bolt and nut of high-strength corrosion-resistant bronze alloy. Copper pressure bar. Bolt and nut of hex design., Splicing, tapping or terminating conductors in power and grounding electrical connection. |
| Suitable for | Round conductor |
| Standard | UL E9809 |
| Type | Split-Bolt |
| Color | Metallic |
| Application | Splicing, tapping or terminating conductors in power and grounding electrical connection. |
| Country of Origin (subject to change) | Mexico |
| Package Quantity | 1 |
Split-Bolt Connector, 8 sol to 4 sol, BLACKBURN, Mfr# 4H
$5,49
-3% / ea
with subscription
Free shipping will be applied on orders over $50
Split-Bolt Connector, Body Finish Plain, Body Material Bronze, For Conductor Material Copper, For Minimum Equal Wire Size 8 AWG, For Maximum Equal Wire Size 4 AWG, For Minimum Run Wire Size (2) 8 AWG, For Maximum Run Wire Size (2) 4 AWG, For Minimum Tap Wire Size 8 AWG, For Maximum Tap Wire Size 4 AWG, Head Style Hex Head, Head Width 0.53 in, Hex Nut Size 0.719 in, Maximum Voltage 600 V, Torque 135 in-lb, Compatible Manufacturer Model Number 4H, Overall Length 1.06 in, Overall Width 0.53 in
9999 in stock
Must order in multiples of 1
Subtotal:
$5.49
