Specific Fitting Shape
Straight Reducing Adapter
Standards
IAPMO Z1117, NSF 372, NSF 61
Includes Center Stop
Not Applicable
Fitting Side B Pipe Size
Not Applicable
Fitting Side A Pipe Size
Not Applicable
Fitting Side A Tube Outer Diameter
1 3/8 in
Fitting Side A Copper Tube Size
1 1/4 in
Thread Sealant Type
Not Applicable
Resistance Properties
Corrosion-Resistant
Flange Outside Diameter
Not Applicable
Flange Thickness
Not Applicable
Fitting Side B Tube Outer Diameter
5/8 in
Fitting Side B Copper Tube Size
1/2 in
Fitting Side A Connection Type
FTG
Bolt Hole Diameter
Not Applicable
Vacuum Rating
-24.5 inHg @ 68 Degrees F
Maximum Operating Pressure
200 psi
Number of Bolt Holes
Not Applicable
Compatible Tube Material
Copper
Maximum Operating Temperature
250 Degrees F
Includes Pre-Applied Thread Sealant
Pre-Applied Thread Sealant Not Included
Minimum Operating Temperature
0 Degrees F
Compatible Copper Tube Type
Type K, Type L, Type M
Fitting Side B Connection Type
Press-Fit
Compatible Tube Wall Thickness
Not Applicable
Required Tool Jaw Size
1/2 in
Compatible Tool Brand
Milwaukee, Ridgid, RMES, Rothenberger
Compatible Tube Hardness
Not Applicable
Compatible Tool Jaw Manufacturer Model Number
Not Applicable
Fitting Side 2 Connection Type
Press-fit
Fitting Features
Not Applicable
Operating Temperature - Maximum
250 Degrees F
Fitting Side 1 Copper Tube Size
1 1/4 in
O-Ring Color Code
Not Applicable
Fitting Side 2 Tube Outer Diameter
5/8 in
Center Stop Type
Not Applicable
Fitting Side 1 Connection Type
FTG
Center-to-End 1 Length
Not Applicable
Operating Temperature - Minimum
0 Degrees F
For Media Type
Potable Water
Fitting Side 1 Pipe Size
Not Applicable
Fitting Side 2 Copper Tube Size
1/2 in
Operating Pressure - Maximum
200 psi
Fitting Side 1 Tube Outer Diameter
1 3/8 in
Center-to-End 2 Length
Not Applicable
Fitting Side 2 Pipe Size
Not Applicable
Country of Origin (subject to change)
China
