HP
1/2 (Primary); 1/3 (Secondary)
Body Material
Cast Iron (Primary); Plastic (Secondary)
Alarm Output
Audible, Phone System, Visual, WiFi
Switch Actuation
Vertical Float
Flow Rate @ 10 Ft. of Head
61.0 gpm (Primary); 30.0 gpm (Secondary)
Max. Head
23.0 ft (Primary); 22.0 ft (Secondary)
Includes
Battery Box, Battery Charger, Check Valve, Controller with Internet Connection, Mount, Primary Pump
GPH of Water @ 15 Ft. of Head
2700 (Primary), 1200 (Secondary)
Motor Type
Permanent Split Capacitor (Primary), Brush Type DC (Secondary)
Manufacturers Warranty Length
3 yr
Max. Flow (GPH) - Back-Up
2340
Item - Sump Pumps
Sump/Battery Back-Up System
Max. Flow (GPH) - Pumps
2500
Alarm Output - Pumps
Audible, Phone System, Visual, WiFi
For Use With
Dewatering Systems
Pump Body Material
Cast Iron (Primary), Plastic (Secondary)
Shaft Seal Material - Pumps
Carbon, Ceramic, Nitrile Rubber
Max. Dia. Solids (In.) - Back-Up
1/4
GPM of Water @ 20 Ft. of Head
25 (Primary), 6 (Secondary)
GPM of Water @ 15 Ft. of Head
45 (Primary), 20 (Secondary)
Impeller Material - Pumps
Glass Filled Polypropylene
Max. Head (Ft.) - Back-Up
22
GPM of Water @ 10 Ft. of Head
61 (Primary), 30 (Secondary)
Duty
Continuous (Primary), Intermittent (Secondary)
GPH of Water @ 0 Ft. of Head
4100 (Primary), 2000 (Secondary)
Max. Diameter Solids
1/2 in
Impeller Material
Polypropylene (Primary)
Alarm Duration - Pumps
Continuous
GPH of Water @ 5 Ft. of Head
4320 (Primary), 2340 (Secondary)
Item
Sump/Battery Back-Up System
Max. Liquid Temp.
130 Degrees F
GPH of Water @ 10 Ft. of Head
3660 (Primary), 1800 (Secondary
GPM of Water @ 5 Ft. of Head
72 (Primary), 39 (Secondary)
Primary Pump Shaft Seal Material
Buna-N
Secondary Pump Duty Cycle
Intermittent
Primary Pump Flow Rate @ 5 Ft. of Head
72.0 gpm
Primary Pump Maximum Solids Diameter
1/2 in
Duty Cycle
Continuous; Intermittent
Secondary Pump Maximum Head
22 ft
Primary Pump Flow Rate @ 10 Ft. of Head
61.0 gpm
Switch Electrical Connection
Integral, Piggyback
Primary Pump Duty Cycle
Continuous
Primary Pump Overall Height
20 1/2 in
Flow Rate @ 15 Ft. of Head
45.0 gpm (Primary); 20.0 gpm (Secondary)
Primary Pump Width at Widest Point
11 in
Primary Pump Flow Rate @ 20 Ft. of Head
25.0 gpm
Primary Pump Flow Rate @ 15 Ft. of Head
45.0 gpm
Flow Rate @ 20 Ft. of Head
25.0 gpm (Primary)
Flow Rate @ 5 Ft. of Head
72.0 gpm (Primary); 39.0 gpm (Secondary)
Width at Widest Point
11 in
Primary Pump Body Material
Cast Iron
Secondary Pump Shaft Seal Material
Ceramic
Discharge
1-1/2 in M PVC Glue
Secondary Pump Flow Rate @ 15 Ft. of Head
20.0 gpm
Primary Pump Maximum Head
23 ft
Discharge Standard
PVC Glue
Secondary Pump Flow Rate @ 5 Ft. of Head
39.0 gpm
Secondary Pump Body Material
Plastic
Primary Pump Rated Voltage
120V AC
Primary Pump Impeller Material
Glass Filled Polypropylene
Secondary Pump Flow Rate @ 10 Ft. of Head
30.0 gpm
Secondary Pump Rated Voltage
12V DC
Country of Origin (subject to change)
United States
