| Property | Value |
|---|---|
| CAD Available | Yes |
| Item | Self Locking Thread Insert |
| Internal Thread Size | 5/8 |
| Material | Carbon Steel |
| Overall Length | 11/16 in |
| Insert Diameter | 7/8 in |
| External Thread Size | 7/8 |
| Wall Type | Heavy Wall |
| Thread Type | UNC Internal/UNC External |
| Drill Bit Size | 49/64 in |
| Installation Method | Screwdriver, Bolt/Nut, or Power Drive Tool |
| Minimum Installation Depth | 13/16 in |
| Tensile Strength (PSI) | 78,300 psi |
| Application | For Use on Metal |
| Brinell Hardness | 163 |
| External Thread Class | 2A |
| Power Driver | 4ZE59 |
| Internal Thread Class | 2B |
| Tap Sizes | 7/8-9 |
| Finish | Black Phosphate |
| Features | Pre-Applied Adhesive Activates On Installation, Vibration Resistant |
| Min. Full Thread Depth | 13/16 |
| Series | E-Z LOK |
| Tensile Strength | 78,300 psi |
| Thread Direction | Right Hand |
| Maximum Hole Diameter | 0.766 in |
| Material Grade/Class | 12L14 |
| Internal Thread Fit | 2B |
| Full Cure Time | 72 hr |
| Compatible Material | Metal |
| External Thread Fit | 2A |
| System of Measurement | Inch |
| Compatible Tap Size | 7/8 |
| Country of Origin (subject to change) | United States |
| Package Quantity | 5 |
Heavy Wall Self Locking Thread Insert, 5/8"-11 Int Thrd Sz, Carbon Steel, 5 PK, E-Z Lok, Mfr#: 329-10-PK5
$11.35
Free shipping will be applied on orders over $50
Self Locking Thread Insert, Compatible Material Metal, Compatible Tap Size 7/8 In.-9, Drill Bit Size 49/64 in, External Thread Fit 2A, External Thread Size 7/8 In.-9, Finish Black Phosphate, Insert Diameter 7/8 in, Internal Thread Fit 2B, Internal Thread Size 5/8 In.-11, Material Steel, Material Grade/Class 12L14, Maximum Hole Diameter 0.766 in, Minimum Installation Depth 13/16 in, Overall Length 11/16 in, System of Measurement Inch, Thread Direction Right Hand, Thread Type Coarse
9999 in stock
