Item - Motion Sensing and Dimming
Vacancy Sensor
Communication Method - Motion Sensing and Dimming
Hard Wired
Sensing Technology
Passive Infrared (PIR)
Installation Location - Motion Sensor
Wall Switch Box
Coverage at Suggested Mounting Height
900 sq ft
Operating Voltage - Motion Sensing and Dimming
120 V AC
Color - Motion Sensing and Dimming
White
Time Delay Adjustment Method - Motion Sensor
Adjustable
Time Delay - Motion Sensor
1 min, 15 min, 30 min, 5 min
Lighting Technology
Fluorescent, Halogen, Incandescent, LED
For Use With
Incandescent, Halogen, CFL and LED Lighting Loads
Description/Special Features
Line Voltage 2-Wire Dimming, Manual-On/Auto-Off
Coverage Angle - Motion Sensor
180 Degrees
Sensor Type
Passive Infrared
Installation Type
Switch Box
Standards
NOM, Title 20/24 Compliant, UL Listed
Suggested Mounting Height - Motion Sensor
4 ft
Max. Capacity @ 120VAC
150W (CFL, LED), 600W (Halogen, Incandescent)
Timer Range
1, 5, 15, 30 min.
Communication Method
Hard Wired
Compatible with Series
Universal
Includes Dimming Switch
Dimming Switch Included
Includes Motion Sensor
Yes
Includes Wall Plate
Wall Plate Not Included
Minimum Operating Temperature
32 Degrees F
Dimming Method
Line Voltage
Coverage Angle
180 Degrees
Installation Location
Wall
Load Rating @ 120V AC
150W (CFL, LED), 600W (Halogen, Incandescent)
Maximum Coverage Area
900 sq ft
Minimum Coverage Area
400 sq ft
Sensor Operation
Photocell, Vacancy
Manufacturer Warranty
5 yr
Maximum Operating Temperature
104 Degrees F
Maximum Mounting Height
4 ft
Minimum Mounting Height
Not Applicable
Country of Origin (subject to change)
China
