| Item - Plugs and Receptacles | Watertight Locking Plug |
| Wiring Style | Standard |
| Shrouded / Non-Shrouded | Shrouded |
| Grade - Plugs and Receptacles | Industrial |
| Amps - Plugs and Receptacles | 30 |
| NEMA Plug Configuration - Plugs and Receptacles | L17-30P |
| Voltage - Plugs and Receptacles | 600V AC |
| Number of Poles | 3 |
| Number of Wires | 4 |
| Phase | Three |
| Amps | 30 |
| Number of Blades | 4 |
| Voltage Rating | 600V AC |
| Corrosion Resistant | Yes |
| Grade | Industrial |
| Voltage | 600VAC |
| Color | Yellow |
| Material | Thermoplastic Elastomer |
| Housing Color | Yellow |
| NEMA Configuration | L17-30 |
| Special Features | Corrosion resistant |
| Color - Plugs and Receptacles | Orange/Yellow |
| NEMA Rating | 4, 4X, 12, 6, 6P |
| Current Rating | 30 A |
| For Maximum Cable Diameter | 0.93 in |
| Item | Watertight Locking Plug |
| IP Rating | IP69K |
| Shrouded | Yes |
| For Minimum Cable Diameter | 0.64 in |
| Standards | ANSI/UL 498 File E17740, CSA Certified C22.2 No. 42, NSF/ANSI/3-A 14159-1 |
| Cord Size | 0.640 in to 0.930 in |
| NEMA Plug Configuration | L17-30P |
| Antimicrobial | Yes |
| For Environment | Washdown |
| Resistance Properties | Antimicrobial, Corrosion Resistant |
| Housing Material | Thermoplastic Elastomer |
| Market | Industrial |
| Country of Origin (subject to change) | United States |
| Package Quantity | 1 |
WT LckPlg, ;30 A;Yellow, Elastmr, 4Blds, ERICSON, Mfr# 2526-PW6P-AM
$78,95
Free shipping will be applied on orders over $50
Watertight Locking Plug, Current Rating 30 A, Housing Color Yellow, Housing Material Thermoplastic Elastomer, NEMA Plug Configuration L17-30P, Number of Blades 4, Number of Poles 3, Phase Three, Resistance Properties Antimicrobial, Corrosion Resistant, Voltage Rating 600V AC, Wiring Style Standard, For Maximum Cable Diameter 0.93 in, For Minimum Cable Diameter 0.64 in, Grade Industrial, IP Rating IP69K, Market Industrial, Shrouded Yes
9999 in stock
