| Item | Instant Reverse Motor |
| Motor Design | Capacitor-Start |
| Motor Enclosure Design | Open Dripproof |
| HP | 1/4 |
| Nameplate RPM | 1,725 |
| Frame | 48 |
| Voltage | 115V AC |
| Full Load Amps | 5.2 |
| Phase | Single |
| Motor Thermal Protection | None |
| Ins. Class | B |
| Motor Mounting Type | Rigid Base |
| Motor Bearings | Ball |
| Shaft Dia. | 1/2 in |
| Number of Wires | 4 |
| Motor Shaft Design | Flat |
| Motor Mounting Position | All Angle |
| Ambient Temperature | 40 Degrees C |
| Application | For Door Operators, Machine Tools, Cranes, Hoists, Gates and Remote Control Instant Reversibility |
| Motor Service Factor | 1.35 |
| Hz | 60 |
| Motor Application | Garage/Gate Opener |
| Voltage Compatibility | 115/208-230V AC, 115/230V AC, 115V AC, 120/240V AC, 120V AC |
| RPM Range | 1,701-1,800 |
| Standards | CSA, UL Recognized |
| Shaft Length | 1 1/2 in |
| Nominal Efficiency | 52.6 % |
| Length Less Shaft | 8 1/16 in |
| Motor Shaft Rotation | CCW, CW |
| No. of Speeds | 1 |
| Weight | 14 lb |
| Extended Thru-Bolts | Yes |
| Conduit Box Location | Exterior |
| Motor Frame Material | Steel |
| Overall Length | 9 9/16 in |
| Duty Cycle | Continuous |
| Max. Ambient Temp. | 40 Degrees C |
| Country of Origin (subject to change) | Mexico |
| Package Quantity | 1 |
Instant Rev Motor, 1/4 HP, 1725 RPM, 115 V, MARATHON MOTORS, Mfr# 5KC35GNA488
$265,99
-$7.98 / ea
with subscription
Free shipping will be applied on orders over $50
Instant Reverse Motor, Single Phase, Motor Design Capacitor-Start, 1/4 HP, Nameplate RPM 1,725, No. of Speeds 1, Voltage 115V AC, Full Load Amps 5.2, 48 Frame, 60 Hz, Motor Service Factor 1.35, Motor Thermal Protection None, Ins. Class B, Max. Ambient Temp. 40 Degrees C, Duty Cycle Continuous, Motor Shaft Rotation CCW, CW, Motor Enclosure Design Open Dripproof, Motor Mounting Type Rigid Base, Motor Mounting Position All Angle, Number of Wires 4, Motor Frame Material Steel, Shaft Dia. 1/2 in
9999 in stock
Must order in multiples of 1
