Item | Linear Ball Bearing |
Type | Open |
Bore Dia. | 0.625 in |
Outside Dia. | 1 1/8 in |
Material | Steel |
Dynamic Load Capacity (Lb.) | 105 |
Steady State Speed | 10 fps |
Required Housing Bore Dia. (In.) | 1.125 in |
Between Grooves (mm) | 1.108 in |
Dimension T | 0.625 |
For Use With | Thomson Shafting |
Slot Angle (Degrees) | 60 Degrees |
Dimension E | 0.38 in |
Temp. Range (F) | 0 - 300 |
Inside Dia. Tolerance | +/-.001 |
Length (In.) | 1 1/2 in |
Dimension C | 1.5 in |
Dimension C1 | 1.108 in |
Slot Width (In.) | 0.38 in |
Accelerated Speed | 450 fps |
Dimension C2 | 0.056 |
Self-Alignment | Not Self-Aligning |
Dynamic Load Capacity (N) | 105 lbf |
Operating Temperature Range | 0 Degrees F to 500 Degrees F |
Inside Dia. | 5/8 in |
Brand & Series | THOMSON Precision |
Included Wiper Seals | No Wipers |
Series | Precision |
System of Measurement | Inch |
Minimum Operating Temperature | 0 Degrees F |
Maximum Operating Temperature | 500 Degrees F |
Country of Origin (subject to change) | Mexico |
Package Quantity | 1 |
Hey, you! Hold everything and check this out
we've got a killer discount for you first order
we've got a killer discount for you first order
Use this discount code at the checkout - SAVE5%
Ball Bushing, Bore Dia 0.625 In, THOMSON, Mfr# OPN101824
$65,35
Free shipping will be applied on orders over $50
Linear Ball Bearing, Type Open, Inside Dia. 5/8 in, Outside Dia. 1 1/8 in, Material Steel, Accelerated Speed 450 fps, Between Grooves (mm) 1.108 in, Dimension B -, Dimension C 1.5 in, Dimension C1 1.108 in, Dimension C2 0.056, Dimension d -, Dimension E 0.38 in, Dimension F -, Dimension G -, Dimension T 0.625, Dynamic Load Capacity (N) 105 lbf, For Use With Thomson Shafting, Inside Dia. Tolerance +/-.001, Maximum Operating Temperature 500 Degrees F, Minimum Operating Temperature 0 Degrees F
9999 in stock
Must order in multiples of 1
Subtotal:
$65.35
Final shipping and tax calculated in checkout
Brand Name:
THOMSON
Mfr #:
OPN101824
Availability: Ships in 10 days
SKU: GRG1494087
Category: Ball Bushing Bearings
